The Rode NT5 is RØDE’s premier small-diaphragm cardioid condenser microphone, sometimes referred to as a ‘pencil mic’.
- Externally biased condenser
- Gold sputtered 1/2” capsule
- Heavy-duty satin-nickel plated body
- Dual power operation
- Surface mount circuitry
- Low noise
- Full frequency response
- Available as Certified Match Pair
NT5 SPECIFICATIONS
Acoustic Principle | Pressure Gradient |
Active Electronics | JFET impedance converter with bipolar output buffer |
Capsule | 0.50″ |
Polar Pattern | |
Address Type | End |
Frequency Range | 20Hz – 20kHz |
Output Impedance | 100Ω |
Maximum SPL | 143dBSPL |
Maximum Output Level | 13.9mV (@ 1kHz, 1% THD into 1KΩ load) |
Sensitivity | -38.0dB re 1 Volt/Pascal (12.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz |
Equivalent Noise Level (A-weighted) | 16dBA |
Power Options | |
Weight | 101.00g |
Dimensions | 118.00mmH x 20.00mmW x 20.00mmD |
Output |
